Growatt THOR Series EV Charger | 7.3kW / 11kW / 22kW AC | 1 & 3Phase

The Growatt THOR Series EV Chargers provide flexible AC and DC charging solutions for residential, commercial, and fleet applications. The range includes single-phase AC charging 7.3kW, three-phase AC charging at 11kW and 22kW DC fast-charging option.

Designed for smart and reliable EV charging, selected THOR models support WiFi, 4G, Ethernet, APP/RFID activation, OCPP 1.6, load balancing and PV linkage charging. The AC models feature Type 2 charging compatibility

Key Features

• Growatt THOR smart EV charging platform
• AC charging  22kW
• Single-phase and three-phase configurations
• Type 2 AC charging interface

• PV Linkage charging for solar-integrated systems
• Fast, off-peak and load-balancing modes on applicable models
• APP, RFID and Plug & Charge activation on applicable AC models
• WiFi / 4G / Ethernet connectivity depending on model
• OCPP 1.6 support on applicable smart models
• IP65 protection for the AC THOR models
• Multiple electrical protection functions
• Wall or floor mounting options on applicable AC modelSuitable for residential, commercial and fleet charging



  Technical Specifications:

  • Brand: Growatt
  • Series: THOR
  • Models: THOR 07AS, THOR 11AS & THOR 22AS
  • Charger Type: AC EV Charger & DC Fast Charger
  • Power Output:  7.3kW, 11kW & 22kW
  • Phase: Single-Phase & Three-Phase
  • AC Charging Interface: IEC 62196-2 Type 2
  • DC Charging Interface: CCS2
  • Maximum AC Current: Up to 32A
  • Communication: WiFi / LAN / 4G, depending on model
  • Charging Activation: APP / RFID / Plug & Play, depending on model
  • Charging Modes: Fast, PV Linkage, Off-Peak & Load Balancing
  • Smart Features: Smart Load Balancing & Solar PV Integration
  • Protection: Over-voltage, under-voltage, overload, short-circuit, earth-leakage, over-temperature and lightning protection
  • RCD Protection: Type A + 6mA DC fault-current protection on applicable AC models
  • Protection Rating: IP65 for applicable AC THOR models
  • Cooling: Natural Cooling for AC models



    Dimensions:

    • THOR 07AS: 240 × 380 × 164 mm
    • THOR 11AS: 240 × 380 × 164 mm
    • THOR 22AS: 240 × 380 × 164 mm

    • THOR 12AS:246 × 382 × 154 mm
