Deye Smart EV Charger – 11kW & 22kW, 3-Phase, Type 2

The Deye Smart EV Charger is an intelligent AC charging solution designed for electric vehicles. Available in 11kW and 22kW variants, it supports smart charging, remote monitoring and control through Deye Cloud/Solarman, with WiFi, Bluetooth and LoRa communication. With IP66 protection and built-in safety features, it is suitable for both indoor and outdoor installations

Key Features

• Available in 11kW & 22kW
• 3-Phase AC charging
• Type 2 charging gun
• Plug & Play charging
• Scheduled charging
• Solar-only charging mode
• WiFi, Bluetooth & LoRa
• Remote monitoring via Deye Cloud/Solarman
• IP66 protection
• 6mA DC leakage protection
• Type II surge protection
• Suitable for outdoor installation



  echnical Specifications

  • Model: SUN-EVSE11K01-AC / SUN-EVSE22K01-AC
  • Rated Power: 11kW / 22kW
  • Phase: 3-Phase / 3-Phase
  • Rated Current: 16A / 32A
  • Rated Voltage: 400V AC / 400V AC
  • Frequency: 50/60Hz
  • Charging Type: AC
  • Connection: 3L + N + PE
  • Charging Cable: 4.2m
  • Communication: WiFi, Bluetooth & LoRa
  • Leakage Protection: 6mA DC
  • Surge Protection: Type II
  • IP Rating: IP66
  • Operating Temperature: -40°C to +55°C
  • Charging Mode: Plug & Play / Scheduled Charging
  • Charging Connector: Type 2
  • Application: Indoor & Outdoor EV Charging



    Dimensions

    • 11kW – SUN-EVSE11K01-AC: 104 × 264 × 57.5 mm
    • 22kW – SUN-EVSE22K01-AC: 104 × 264 × 57.5 mm
