ABB Terra EV Charger 22kW – 3-Phase, Type 2 Socket,

The ABB Terra  22kW EV Charger is a smart AC charging solution designed for reliable electric vehicle charging. It features a Type 2 socket, 3-phase 32A output and RFID authentication, making it suitable for residential, commercial and workplace EV charging applications. The charger supports network connectivity and OCPP 1.6 for connected charging management

Key Features

• 22kW AC charging power
• 3-Phase / 32A
• Type 2 socket
• RFID authentication
• Smart connected charging
• WiFi, Ethernet & Bluetooth
• OCPP 1.6J support
• Built-in electrical protection
• Wall-mounted installation



  Technical Specifications

  • Brand: ABB
  • Series: Terra AC
  • Model: TAC-W22-T-R-0
  • Product ID: 6AGC082152
  • Charging Power: 22kW
  • Phase: 3-Phase
  • Maximum Current: 32A
  • Input Voltage: 380–420V AC
  • Output Voltage: 320–480V AC
  • Frequency: 50/60Hz
  • Connector: Type 2 Socket
  • Number of Sockets: 1
  • Authentication: RFID
  • Communication: WiFi, Ethernet, Bluetooth
  • Protocol: OCPP 1.6J
  • Protection Rating: IP54
  • Impact Protection: IK10
  • Charging Mode: Mode 3, Level 2



    Dimensions

    • 22kW – 3-Phase: 320 × 195 × 110 mm
